• Linux system with 10” multi-touch display with dedicated app
• Acquisition of gas parameters and warning signals of multiple peripherals connected via a single cable that meets the specifications of communication with Modbus RTU protocol on RS 485 network
• Real-time reading of parameters (pressure, temperature, etc.)
• Supervision until a theoretical maximum of 247 alarm modules*
• Compatible with all devices equipped with RS485 interface and MODBUS-RTU protocol (contact MD for more information)
• Intuitive graphical interface for configuration and customization of monitored peripherals and their parameters and alarm messages
• Presence of synoptics for the most common monitored alarm modules (possibility of adding customized synoptics according to customer needs)
• Ability to organize monitored alarm peripherals in a tree structure for rapid message localization active alarms
• Unlimited alarm history, with alarm event search function by area, by month or by individual alarm module
• Internet connection via Ethernet or Wi-Fi cable (optionally available 3G modem for internet connection via data SIM card)
• Optional service “MD Gas Monitor” for monitoring via internet on dedicated account (includes data visualization in real time, synoptics, email notification and archive consultation of all alarm events)
• Audible alarm signaling speaker
• Alarm silencing function with adjustable menu reset timer
• Presence of blue LEDs for POWER ON signaling, green for alarm absence, yellow and red for medical gas network alarms
• Relay outputs for alarm signaling and offline of monitored alarm modules
• Black external containment box

* the real number depends on the total length of the cable, the presence of disturbances in the line, and the amount of data transmitted from the alarm modules to Sentinel
